2021.01.20	"Catalogue Update Information"
2020.02.19	New Model : 800MHz ~ 4000MHz, 550W All Solid-State Power Amplifier "GA801M402-5757R"
2020.02.13	New Model : 2500MHz ~ 6000MHz, 200W All Solid-State Power Amplifier "GA252M602-5353R"
2020.02.13	New Model : 2500MHz ~ 6000MHz, 100W All Solid-State Power Amplifier "GA252M602-5050R"
2020.02.13	New Model : 100kHz ~ 1000MHz, 50W All Solid-State Power Amplifier "A101K102-4747R"
2020.02.13	New Model : 2856MHz ± 10MHz, 600W Pulse All Solid-State Power Amplifier "CA2856BW20-5858RP"

RF Power Amplifiers


RF Power Amplifiers	Small Signal & Low Noise Amplifiers

Connector Modules


Small Signal Amplifiers	Power Dividers / Combiners

Low Noise Amplifiers	Mixers

Directional Couplers	Quadrature Hybrids

Bias Tees	RF Power Detectors

8P & Surface Mount Devices

	Double Balanced Mixers
	Power Dividers / Combiners
	PIN Diodes Attenuators
	Quadrature Hybrid
	Directional Couplers
	Frequency Doublers
	Balun Transformers
	180°Hybrid Junctions

RF Power Amplifiers New Lineup

Model Number	Specifications	PDF
CA500BW1-7272R	500MHz ± 0.5MHz
	15kW @ 2dB Comp.
CA500BW2-8085RP	500MHz ± 1MHz
	300kW @ Peak
CA1300BW1-6068R-SL	1300MHz ± 1MHz
	7kW @ 1dB Comp.
GA252M602-5050R	2500MHz ～ 6000MHz
	100W @ 1dB Comp.
GA252M602-5353R	2500MHz ～ 6000MHz
	200W @ 1dB Comp.
A101K102-4747R	100kHz ～ 1000MHz
	50W @ 3dB Comp.
CA2856BW20-5858RP	2856MHz ± 10MHz
	600W @ Peak
CA5712BW20-5959RP	5712MHz ± 10MHz
	800W @ Peak
GA801M402-5757R	800MHz ～ 4000MHz
	550W @ 3dB Comp.

Small Signal Amplifier

Model Number	Specifications	PDF
AA1000-0S	9kHz～8000MHz
	Po:+12dBm/Gain:+12dB
AA1010-0S	9kHz～8000MHz
	Po:+12dBm/Gain:+24dB
AA1020-0S	9kHz～8000MHz
	Po:+12dBm/Gain:+35dB
AA1030-0S	9kHz～4000MHz
	Po:+20dBm/Gain:+12dB
AA1040-0S	9kHz～4000MHz
	Po:+20dBm/Gain:+24dB
AA1050-0S	9kHz～4000MHz
	Po:+20dBm/Gain:+36dB
AA1060-0S	1MHz～3000MHz
	Po:+27dBm/Gain:+18dB
AA1070-0S	1MHz～3000MHz
	Po:+27dBm/Gain:+28dB
AA1080-0S	1MHz～3000MHz
	Po:+29dBm/Gain:+18dB
AA1090-0S	1MHz～3000MHz
	Po:+29dBm/Gain:+29dB
AA1100-0S	9kHz～3500MHz
	Po:+16dBm/Gain:+16dB
AA1110-0S	9kHz～3500MHz
	Po:+16dBm/Gain:+21dB
AA1120-0S	9kHz～3500MHz
	Po:+17dBm/Gain:+31dB
AA1130-0S	9kHz～3500MHz
	Po:+17dBm/Gain:+43dB

Low Noise Amplifier

Model Number	Specifications	PDF
LA1000-0S	500MHz～8000MHz
	NF:2dB/Gain:+21dB
LA1010-0S	500MHz～8000MHz
	NF:2dB/Gain:+34dB
LA1020-0S	500MHz～8000MHz
	NF:2dB/Gain:+47dB
LA1030-0S	600MHz～4200MHz
	NF:1.2dB/Gain:+20dB
LA1040-0S	600MHz～4200MHz
	NF:1.2dB/Gain:+32dB
LA1050-0S	600MHz～4200MHz
	NF:1.2dB/Gain:+44dB
LA1060-0S	30MHz～4200MHz
	NF:2dB/Gain:+18dB
LA1070-0S	30MHz～4200MHz
	NF:2dB/Gain:+35dB
LA1080-0S	30MHz～4200MHz
	NF:2dB/Gain:+48dB
LA1090-0S	5GHz～10.5GHz
	NF:2dB/Gain:+19dB
LA1100-0S	5GHz～10.5GHz
	NF:2.2dB/Gain:+31dB
LA1110-0S	5GHz～10.5GHz
	NF:2.2dB/Gain:+42dB

RF Swicth

Model Number	Specifications	PDF
SW1000-0S	9kHz～6000MHz
	SPDT
SW1010-0S	9kHz～6000MHz
	SP4T
SW1030-0S	9kHz～6000MHz
	SP8T
SW1040-0S	9kHz～6000MHz
	SPDT / Hi-Isolation
SW1050-0S	9kHz～6000MHz
	SP4T / Hi-Isolation
SW1070-0S	9kHz～6000MHz
	SP8T / Hi-Isolation

ISO9001:2015 certified

Issuing Date:January. 26, 2018

Initial Certification Date: July 6, 2012

applicable to :

Design, development and manufacture of RF/microwave products
